ชุดรางเครนสำเร็จรูป (Light Crane tracks & Components) ออกแบบมาให้สามารถประกอบเข้ากับหน้างานได้เลย พร้อมมีจุดเด่นที่เลื่อนไหลได้ดีกว่าอุปกรณ์แบบ Trolley แถมไม่มีการเสียดสีและเกิดประกายไฟ สามารถต่อเป็นเครนแบบ 4 และ 6 ทิศทางได้
| Product Code | Track Size | Description | Length / Size | Net Weight (kg) |
| KT96 01 110 | KH 100 | Steel tracks | 1.0 m. | 4.1 |
| KT96 01 210 | 2.0 m. | 8.2 | ||
| KT96 01 310 | 3.0 m. | 12.3 | ||
| KT96 01 410 | 4.0 m | 16.4 | ||
| KT96 01 510 | 5.0 m | 20.5 | ||
| KT96 01 120 | KH I | Steel tracks | 1.0 m. | 6.4 |
| KT96 01 220 | 2.0 m. | 12.8 | ||
| KT96 01 320 | 3.0 m. | 19.2 | ||
| KT96 01 420 | 4.0 m | 25.6 | ||
| KT96 01 520 | 5.0 m | 32 | ||
| KT96 01 620 | 6.0 m | 38.4 | ||
| KT96 01 130 | KH IIL | Steel tracks | 1.0 m. | 13.2 |
| KT96 01 230 | 2.0 m. | 26.4 | ||
| KT96 01 330 | 3.0 m. | 39.6 | ||
| KT96 01 430 | 4.0 m | 52.8 | ||
| KT96 01 530 | 5.0 m | 66 | ||
| KT96 01 630 | 6.0 m | 79.2 | ||
| KT96 01 140 | KH-II | Steel tracks | 1.0 m. | 17 |
| KT96 01 240 | 2.0 m. | 34 | ||
| KT96 01 340 | 3.0 m. | 51 | ||
| KT96 01 440 | 4.0 m | 68 | ||
| KT96 01 540 | 5.0 m | 85 | ||
| KT96 01 640 | 6.0 m | 102 | ||
| KT96 04 520 | KH I | Curved rail | R=1M 60° | 6.7 |
| KT96 04 620 | R=1M 90° | 10 | ||
| KT96 04 440 | KH II | R=1.5M 45° | 20.3 | |
| KT96 04 540 | R=1.5M 60° | 26.9 | ||
| KT96 04 640 | R=1.5M 90° | 36.5 | ||
| KT96 02 010 | KH-100 | Joint Bolt Set | L=35 mm | 0.05 |
| KT96 02 020 | KH-I | L=40 mm | 0.1 | |
| KT96 02 040 | KH-IIL & II | L=80 mm | 0.44 | |
| KT96 07 010 | KH-100 | Joint Bolt Set | L=53 mm | |
| KT96 07 020 | KH-I | L=53 mm | ||
| KT96 07 040 | KH-IIL & II | L=92 mm | ||
| KT96 07 010 | KH-100 | End Cap With Buffer | 0.1 | |
| KT96 07 020 | KH-I | 0.1 | ||
| KT96 07 030 | KH-IIL | 0.44 | ||
| KT96 07 040 | KH-II | 0.44 | ||
| KT96 25 120 | KH-100 & I | Upper Suspension Bracket | A (3″-5″) | 0.65 |
| KT96 25 220 | B (5″-7″) | 0.85 | ||
| KT96 25 320 | C (7″-8″) | 1.2 | ||
| KT96 25 140 | KH-IIL & II | A (3″-5″) | 1.2 | |
| KT96 25 240 | B (5″-7″) | 1.4 | ||
| KT96 25 340 | C (7″-8″) | 1.8 | ||
| KT96 26 020 | KH-100 & I | Upper Susp’n Clamp | Price/Pairราคาต่อคู่ | 2×0.20 |
| KT96 26 040 | KH-IIL & II | 2×1.0 | ||
| KT96 40 020 | KH-100 & I | Ball Head Susp’n Rod | M12 L=30 | 0.08 |
| KT96 40 040 | KH-IIL & II | M15 L=80 | 0.15 | |
| KT96 41 120 | KH-100 & I | Suspension Rod | 80 mm | 0.07 |
| KT96 41 220 | 300 mm | 0.18 | ||
| KT96 41 140 | KH-IIL & II | 100 mm | 0.22 | |
| KT96 41 240 | 300 mm | 0.53 | ||
| KT96 42 010 | KH-100 | Track Suspension Clamp | W58xH83 | 0.3 |
| KT96 42 020 | KH-I | W60xH40 | 0.2 | |
| KT96 42 040 | KH-IIL & II | W80xH59 | 0.8 | |
| KT96 43 020 | KH-100 & I | Spring Clip | Ø2.8 | 0.01 |
| KT96 43 040 | KH-IIL & II | Ø3.4 | 0.02 | |
| KT96 44 020 | KH-100 & I | Ball Head Bolt | M12 L=51 | 0.05 |
| KT96 44 040 | KH-IIL & II | M12 L=70 | 0.11 | |
| KT96 55 010 | KH-100 | Trolley | 100 kgs. | 0.8 |
| KT96 55 020 | KH-I | 300 kgs. | 0.85 | |
| KT96 55 040 | KH-IIL & II | 600 kgs. | 1.95 | |
| KT96 57 020 | KH-100 & I | Load bar | 400 kgs. | 1.39 |
| KT96 57 040 | KH-IIL & II | 1200 kgs. | 2.1 | |
| KT96 57 010 | KH-100 | Crane Suspension Eye | 400 kgs. | 1.1 |
| KT96 57 020 | KH-I | 600 kgs. | 0.9 | |
| KT96 57 040 | KH-IIL & II | 1400 kgs. | 2 | |
| KT96 78 020 | KH-100 & I | Crab Frame | Max. 400 kgs | 13 |
| KT96 78 040 | KH-IIL & II | Max. 1200 kg | 20 | |
| KT96 83 020 | KH-100 & I | End cable clamp | 40 kg | 0.25 |
| KT96 83 040 | KH-IIL & II | 40 kg | 0.25 | |
| KT96 85 020 | KH-100 & I | Cable slider | 0.03 | |
| KT96 85 040 | KH-IIL & II | 0.04 | ||
| KT96 87 020 | KH-100 & I | Cable trolley | 30 kg | 0.28 |
| KT96 87 040 | KH-IIL & II | 30 kg | 0.3 | |
| KT96 25 120AS | KH-100 & I | Complete Short type Suspension Bracket | A (3″-5″) | 2.035 |
| KT96 25 220BS | B (5″-7″) | 2.235 | ||
| KT96 25 320CS | C (7″-8″) | 2.585 | ||
| KT96 25 140AS | KH-IIL & II | A (3″-5″) | 2.07 | |
| KT96 25 240BS | B (5″-7″) | 2.27 | ||
| KT96 25 340CS | C (7″-8″) | 2.62 | ||
| KT96 25 120AL | KH-100 & I | Complete Long type Suspension Bracket | A (3″-5″) | 4.68 |
| KT96 25 220BL | B (5″-7″) | 4.88 | ||
| KT96 25 320CL | C (7″-8″) | 5.28 | ||
| KT96 25 140AL | KH-IIL & II | Bolt #41KH-I 80 mm.KH-II/L 100 mm. | A (3″-5″) | 4.81 |
| KT96 25 240BL | B (5″-7″) | 5.01 | ||
| KT96 25 340CL | C (7″-8″) | 5.41 |
