Diaphragm Pump ALL-FLO Plastic Pump are available in polypropylene and PVDF housing. Its working principle is stroking. It is suitable for viscous liquid or most kinds of chemical
All-Flo diaphragm or AODD plastic plump is designed with simplicity but robust and durable. For high performance, it is common used in conjunction with air compressor. It is convenient, easy installation and maintenance.
ALL-FLO Diaphragm Plastic Pump Its working principle is stroking with diaphragm for pulling or sucking liquid into the pump. Pump materials are available in polypropylene and PVDF housing. Polypropylene is suitable for chemical industry, food industry, painting industry, metal industry, waste water treatment, etc. PVDF offers stronger chemical resistance to both acids and bases, while offering a higher temperature and abrasion protection than polypropylene.
1. ALL-FLO Diaphragm Plastic Pump can be used with liquid containing suspended sediment.
2. All-Flo diaphragm pump is available in various materials that are suitable with various kinds of fluid.
3. All-Flo diaphragm pump is robust, durable with high performance.
| Model | Max. Flow | Max. Air Pressure | Max. Solids | Max. Suction Lift Dry | Max. Suction Lift Dry w/ PTFE | Max. Suction Lift Wet | Weight Polypropylene | Weight PVDF | Air Inlet | Liquid Inlet | Liquid Outlet | Height | Width | Depth |
| ALL-FLO A025 | 5.7 gpm (21.6 lpm) | 120 psi (8.2 bar) | 1/16″ (1.6 mm) | 15 ft-H2O (4.6 m-H2O) | 10 ft-H2O (3.0 m-H2O) | 28 ft-H2O (8.5 m-H2O) | 2.6 lbs (1.2 kg) | 38 lbs (17 kg) | 1/4″ FNPT | 1/4″ Internal (NPT/BSP), 3/4″ External (NPT) | 1/4″ Internal (NPT/BSP), 3/4″ External (NPT) | 6.8″ (173 mm) | 7.3″ (186 mm) | 4.6″ (118 mm) |
| ALL-FLO C038 | 9 gpm (34 lpm) | 120 psi (8.2 bar) | 1/16″ (1.6 mm) | 10 ft-H2O (3.0 m-H2O) | 26 ft-H2O (7.9 m-H2O) | 3.8 lbs (1.7 kg) | 5 lbs (2.3 kg) | 1/4″ FNPT | 3/8″ FNPT/FBSPT | 3/8″ FNPT/FBSPT | 3/8″ FNPT/FBSPT | 7.2″ (183 mm) | 8.6″ (217 mm) | 4.8″ (122 mm) |
| ALL-FLO A050 | 17 gpm (64.6 lpm) | 120 psi (8.2 bar) | 1/8″ (3.2 mm) | 15 ft-H2O (4.5 m-H2O) | 10 ft-H2O (3.0 m-H2O) | 26 ft-H2O (7.9 m-H2O) | 9 lbs (4.1 kg) | 12 lbs (5.4 kg) | 1/4″ FNPT | 1/2″ FNPT/FBSPT | 1/2″ FNPT/FBSPT | 11.4″ (289 mm) | 12.0″ (306 mm) | 7.4″ (187 mm) |
| ALL-FLO A075 | 17 gpm (64.6 lpm) | 120 psi (8.2 bar) | 1/8″ (3.2 mm) | 15 ft-H2O (4.5 m-H2O) | 10 ft-H2O (3.0 m-H2O) | 26 ft-H2O (7.9 m-H2O) | 9 lbs (4.1 kg) | 12 lbs (5.4 kg) | 1/4″ FNPT | 3/4″ FNPT/FBSPT | 3/4″ FNPT/FBSPT | 11.4” (289mm) | 12.0” (306 mm) | 7.4” (187 mm) |
| ALL-FLO A100 | 41 gpm (155.8 lpm) | 120 psi (8.2 bar) | 1/4″ (6.4 mm) | 15 ft-H2O (4.5 m-H2O) | 10 ft-H2O (3.0 m-H2O) | 26 ft-H2O (7.9 m-H2O) | 20 lbs (9.1 kg) | 30 lbs (13.0 kg) | 1/4″ FNPT | 1″ FNPT, FBSPT or ANSI/DIN Flange | 1″ FNPT, FBSPT or ANSI/DIN Flange | 16.3″ (415 mm) | 17.3″ (438 mm) | 8.9″ (226 mm)* |
| ALL-FLO C150 | 130 gpm (492 lpm) | 120 psi (8.2 bar) | 1/4″ (6.4 mm) | 13 ft-H2O (3.9 m-H2O) | 10 ft-H2O (3 m-H2O) | 26 ft-H2O (7.9 m-H2O) | 46 lbs (20.8 kg) | 65 lbs (29.4 kg) | 3/4″ FNPT | 1-1/2″ ANSI/DIN Flange | 1-1/2″ ANSI/DIN Flange | 21.8″ (553 mm) | 20.6″ (523 mm) | 12.2″ (310 mm) |
| ALL-FLO A200 | 160 gpm (605 lpm) | 120 psi (8.2 bar) | 1/4″ (6.4 mm) | 17 ft-H2O (5.2 m-H2O) | 15 ft-H2O (4.6m-H2O) | 29 ft-H2O (8.8 m-H2O) | 56 lbs (25.0 kg) | 84 lbs (38 kg) | 3/4″ FNPT | 2″ ANSI/DIN Flange | 2″ ANSI/DIN Flange | 31.7″ (805 mm) | 23.6″ (600 mm) |
